Commercial Meatball Forming Machine

A commercial meatball forming machine is an automated food processing equipment designed to efficiently produce uniformly shaped, smooth-surfaced meatballs for large-scale operations. It supports various meatball types and is ideal for restaurants, food factories, supermarkets, and catering businesses.

Usage process:

1. No load test machine: After the equipment is installed and powered on, it is strictly prohibited to directly feed. Before use, clean the parts of the hopper, forming mold, etc. that come into contact with the food. Plug in the power, turn on the switch and let the machine run without load first. Carefully check whether the machine is running normally and whether there are any abnormal sounds or lagging phenomena. After confirming that the idle is normal, subsequent debugging and formal production can be carried out.

2. Uniform feeding: Put the prepared and mixed meat slurry into the hopper. The roundness of Rice-meat dumplings shall be debugged before formal production; Prepare about 80 ℃ hot water to put under the pill outlet, start the machine, take 10-20 Rice-meat dumplings to check the smoothness. Adjust the feeding and cutting speed of the inverter according to the demand. The cutting speed is proportional to the feeding speed, and the roundness of the formed Rice-meat dumplings can be better. After adjusting the roundness, it can be officially put into production.

3. Automatic discharge: The equipment adopts an automatic discharge system. The meat paste is pushed to the forming die by the screw, and is extruded from the holes of the forming plate to form Rice-meat dumplings. The forming head can automatically swing from left to right for discharging, and the Rice-meat dumplings can fall dispersedly without stacking and sticking. The formed Rice-meat dumplings automatically fall into the hot water tank at about 80 ℃ below the pill outlet, realizing seamless connection between molding and ripening.

Equipment features:

The Rice-meat dumplings machine is made of 304 stainless steel, with dual motors and dual frequency converters to independently control the blanking and cutting speed. The forming head automatically sways 45 degrees to the left and right, and the meatballs are evenly scattered without accumulation or adhesion. The efficiency is up to 150-300 pieces per minute, suitable for thin or thick slurry raw materials, and can be used for pork balls, fish balls, beef balls, etc. Sizes can be customized according to requirements.

Feature:

Material: The whole machine is made of high-quality 304 food grade stainless steel, which is waterproof, rust proof, structurally stable, and meets food safety production standards. The blade material is high-quality stainless steel, and the mold is made of copper, POM and other materials. The internal transmission of gears is made of heat-treated steel. The whole machine is sturdy, durable, and easy to clean and maintain.

Advanced centrifugal processing technology: The equipment is equipped with a dual motor and dual frequency conversion system, and the feeding and cutting speeds are independently adjustable. Meat pulp is cut into small pieces and gradually forms a spherical shape by high-speed rotating cutting blades and centrifugal force. The molding head continues to oscillate back and forth at a 45 ° angle, causing the balls to disperse and fall into the warm water tank. Paired with fine adjustment of cutting pressure, suitable for meat slurries of different viscosities, with good roundness and less tail material.

Diverse specifications: The equipment is suitable for shaping various meats such as pork, beef, lamb, fish, chicken, as well as meatballs mixed with meat slurry. By adjusting the frequency converter to control the feeding and cutting speed, it can adapt to different conditions of thin or thick slurry, and easily make Rice-meat dumplings, fish balls, beef tendon balls, vegetable balls, etc. Meet diverse production needs.

Safety certification: The equipment has passed CE certification, ISO9001 certification, patent certification, etc., and is popular in many countries such as Europe, America, Asia, and Southeast Asia.

Core structure composition

Rack and Box: The entire machine is made of high-quality 304 food grade stainless steel, which is waterproof, rust proof, structurally stable, and meets food hygiene standards. The body is welded with stainless steel plates, and the distribution box and rear protective cover are made of 3MM stainless steel. Install universal casters at the bottom for flexible relocation and placement in the workshop. The whole machine is sturdy, durable, and easy to clean and maintain.

Processing mechanism (core): The equipment is driven by a motor to swing the forming head left and right by 45 degrees, forming dynamic balance during the meatball forming process. This oscillation evenly distributes the slurry inside the mold, resulting in a smooth and tailless surface and a tight internal structure of the cut meatballs. Paired with fine adjustment of cutting pressure, suitable for meat slurries of different viscosities, with good roundness and less tail material. By changing the mold, various specifications of meatballs can be produced.

Transmission and feeding/discharging mechanism:The equipment is equipped with a dual motor dual frequency conversion system, and the feeding and forming speeds are independently adjustable. The feeding auger adopts a double blade quick disassembly structure, which assists in uniform feeding and is easy to disassemble and clean. The meat slurry is extruded by a screw and pushed towards a forming mold to form meatballs. The forming machine head continuously swings left and right to discharge the material, and the meatballs are dispersed and fall into the water tank or deep frying tank without stacking or sticking.

Simplify the operational process

Clean the hopper, mold, and other contact parts before use. Connect the power supply and conduct a no-load test to confirm normal operation without any abnormalities. Add the meat slurry into the hopper, start the equipment, and first adjust the roundness: place 80 ℃ hot water at the pill outlet, take 10-20 meatballs for observation, adjust the frequency converter to adjust the feeding and cutting speed until the meatballs are smooth and satisfactory. After adjustment, continuous production can be carried out, with the forming head automatically swinging and discharging, and the meatballs falling into the hot water tank. Turn off the power after work, disassemble the mold for cleaning, and keep the equipment clean.

Suitable for various processing industries

Meat processing factory and food factory: The equipment is specially designed for industrial batch production, which can efficiently produce dozens of Rice-meat dumplings products such as fish balls, pork balls, beef balls, chicken balls, shrimp balls, etc. One set of equipment can produce more than 300 kg per hour, which is suitable for mass production scenarios such as meat processing plants and quick frozen food plants. It is the main equipment for standardized mass production of Rice-meat dumplings.

Central Kitchen and Group Meal Canteen: Central Kitchen, Large Canteen, Government Unit Canteen, etc. require large quantities and standardized processing of ingredients. The equipment is easy to operate and highly efficient. The swinging design ensures that the meatballs are evenly scattered without stacking or sticking, and can stably supply various types of meatball dishes, helping group meals achieve standardized meals, reduce costs, and increase efficiency.

Fresh supermarkets and distribution centers: Supermarket post-processing and fresh distribution centers can quickly process fresh meat into various types of meatballs for customers to choose from or distribute. The device is versatile and can be used for fresh food sales, greatly improving the efficiency of fresh food processing and product added value. It is suitable for places such as supermarkets, food service centers, and grocery shopping malls.

Installation and Debugging

Place the meatball machine horizontally on a flat low surface to ensure stability and reliability. Connect the power and ground it reliably, and confirm that the motor rotates counterclockwise. Before use, check if all components have become loose during transportation and if there are any foreign objects in the hopper. Install the drip pipe and connect it to the water source. During operation, ensure that the drip pipe has water to prevent the meat slurry from sticking to the cutting blade. Select the appropriate molding mold according to the required size of the meatballs, align it with the slot for installation, and ensure that it is fixed in place.

Pour the prepared meat paste into the hopper. Place hot water at around 80 ℃ below the pill outlet. Start the machine for no-load testing and observe whether the turning direction of the winch is correct and whether it runs smoothly without any abnormal noise. Trial production of 10-20 meatballs, adjust the feeding and cutting speed of the frequency converter according to the roundness (both must be proportional). Adjusting the pressure screw can control the discharge pressure and ball size. After passing the debugging, normal production can be carried out.

Frequently Asked Questions

How to solve the problem that the automatic beef ball machine starts but does not discharge?

The equipment is running but the meat slurry cannot be squeezed out. The reasons include the reverse connection of the power cord causing the motor to reverse, the position of the pressing rod being too high and not pressurized, or the slurry being too thick. Solution: Swap any two live wires to make the motor rotate forward; Adjust the pressure rod downwards to increase pressure; Adjust the meat paste formula or add ice water to reduce the viscosity.

How to solve the problem that the Rice-meat dumplings produced by the automatic Rice-meat dumplings machine is not shaped?

The cutting blade does not match the feeding speed, the viscosity of the meat slurry is improper, or the adjustment handle is loose. Shutdown is required to readjust the filling amount and tighten the handle. Adjust the frequency converter to make the cutting blade proportional to the feeding speed. If necessary, add starch or ice water to adjust the consistency of the meat filling.

Maintenance method:

Daily maintenance: After daily use, clean the material contact parts such as the hopper, auger, and cutter with water. The motor part must not come into contact with water.

Monthly maintenance:

All moving parts of mechanical components must be kept lubricated.

All chains, sprockets, gears, gear racks, and other rotating components should be regularly lubricated with oil or butter.

All axis rotation joints should be regularly lubricated with oil.

It is recommended to disassemble the cutterhead every two weeks for deep cleaning and check if the screws are fixed. Motor and circuit, check if the power cord is damaged, if the plug is in good contact, and if there is any abnormal noise during motor operation.

Safety Reminder

Do not open the cover or reach inside the machine during operation.

If there is a jamming, power off first and then handle it.
